Product Details:
Payment & Shipping Terms:
|
| Power Supply: | 220V，50~60HZ | Control Mode: | PLC + Touch Panel Screen |
|---|---|---|---|
| Application: | SMT Assembly Production Line | PCB Direction: | L To R, Or R To L |
| PLC: | MITSUBISHI FX1N-40MT | Power: | 600W |
| Lifter Motor Model: | Panasonic Brake Servo Motor | Compressed Air: | 4-6Kg/cm² |
| High Light: | SMT Assembly PCB Loading Machine,PLC PCB Loading Machine,Semiconductor SMT PCB Loader |
||
PCB Loader Unloader
PCB Loading Machine SMT PCB Loader for Semiconductor LD-3
| Features of PCB Loader Unloader LD-3 | |
| 1) PLC control system, high-performance photoelectric sensor, servo motor | |
| 2) Touch screen panel operation | |
| 3) From Right to Left direction (customizable from left to right direction available) | |
| 4) Standard outlet, easy connects with other equipment |
Describtion
Available with connection to SMT and other productions line, Un-man hands free PCB
loading machine provide better protection for the PCB and operator. Machine structure
is designed with compact welded steel frame, and Aluminum extruded profiles for light
weight and yet provides rigidity to the machine.
Specifications of PCB Loader Unloader LD-3
1) Machine size:800(L)*1350(W)*1250(H)mm
2) Magazine size : (50-180) x (100-240)x (110-200) mm, can be customized
3) Max PCB width:within magazine limit
4) PLC:MITSUBISHI FX1N-40MT
5) Lifter motor model:Panasonic brake servo motor
6) Drive motor model:Panasonic 15W AC motor with gear ratio 1:50
7) Power supply:220V,50—60HZ
8) Power: 600W
9) Compressed air:4-6Kg/cm²
Services
1. Quick response within 24 hours;
2. Offer free spare parts and service within one year of warranty,but all the other relative
cost should be on the buyer's account;
3. Technology Support :Provide Demo operation video for training ;If you have time,welcome
to our company,we will arrange engineers to show you the operation;
4. Good and professional after-sales service.
